ISO9001 Power Surge Protection Device 20ka 40ka For Equipment Room

Name: ISO9001 Power Surge Protection Device 20ka 40ka For Equipment Room
Brand: HAMMOND
Price: 1 USD

Quality ISO9001 Power Surge Protection Device 20ka 40ka For Equipment Room wholesale

Brand Name : HAMMOND

Model Number : HDS-D20/10/4P

Place of Origin : China

MOQ : 50

Price : Negotiable

Payment Terms : L/C, T/T

Delivery Time : 8 days

Color : white

Product name : spd

Uc : 385V

Application : lightning protection

Material of Outside Coating : Plastic

Imax : 20KA

Up : ≤ 4.0

Contact Now

Electrical Power System Lightning New Power 20ka 40ka Surge Protector

Product Description

Surge protector, also known as lightning protection, is a variety of electronic devices, instruments, communication lines to provide safety protection of electronic devices. When the electrical circuit or communication lines because of external interference suddenly generate spikes in current or voltage, surge protector can be shunted in a very short period of time on conduction, thereby avoiding damage to other equipment in the circuit surge.

Specification

item	value
Place of Origin	China
Brand Name	HAMMOND
Model Number	HD-C 40
Product name	HD-C 40
Material	Metal
Function	Lighting Protection
CERTIFICATE	ISO9001
Color	white
Maximum Discharging Current	40KA
Nominal Discharging Current	20KA
Maximum Continuous Operating Voltage Uc	385V

Installation requirements

Surge protector using 35MM standard rail installation
For fixed SPD, the conventional installation should follow the following steps.
1)Determine the discharge current path
(2) mark the additional voltage drop caused by the wire at the end of the equipment,.
3) To avoid unnecessary induction loops, the PE conductor of each device should be marked.
(4) the establishment of equipotential connection between the equipment and SPD.
5) To carry out energy coordination of multi-level SPD
In order to limit the protected part after installation and unprotected
